Many customers ask about the different Tires’ rim size, outer diameter, section width and load index, et cetera. Now MELION’s engineers have made a data sheet for your knowledge.
| Tire Size | Ply Rating | Standard Rim | Outer Diameter (mm) | Section Width (mm) | Load Index & Speed Rating | Max Load (KG) Single/ Dual | Max Pressure (KPA) |
|---|---|---|---|---|---|---|---|
| 385/65R22.5 | 20 | 11.75 | 1072 | 389 | 160K | 4500 | 900 |
| 315/80R22.5 | 20 | 9.00 | 1076 | 312 | 157/153L | 4125/3650 | 860 |
| 315/70R22.5 | 20 | 9.00 | 1014 | 312 | 154/150M | 3750/3350 | 900 |
| 295/80R22.5 | 18 | 9.00 | 1044 | 298 | 152/149M | 3550/3250 | 900 |
| 295/75R22.5 | 16 | 9.00 | 1014 | 298 | 146/143L | 3000/2725 | 830 |
| 285/75R24.5 | 16 | 8.25 | 1056 | 283 | 147/144L | 3075/2800 | 830 |
| 275/70R22.5 | 16 | 8.25 | 958 | 276 | 148/145M | 3150/2900 | 900 |
| 265/70R19.5 | 16 | 7.50 | 867 | 262 | 140/138M | 2500/2360 | 775 |
| 255/70R22.5 | 16 | 7.50 | 930 | 255 | 140/137M | 2500/2300 | 830 |
| 245/70R19.5 | 16 | 7.50 | 833 | 248 | 135/133M | 2180/2060 | 830 |
| 235/75R17.5 | 16 | 6.75 | 797 | 233 | 132/130M | 2000/1900 | 775 |
| 225/70R19.5 | 14 | 6.75 | 811 | 226 | 128/126M | 1800/1700 | 760 |
| 215/75R17.5 | 16 | 6.00 | 767 | 212 | 126/124M | 1700/1600 | 700 |
| 205/75R17.5 | 14 | 6.00 | 753 | 205 | 124/122M | 1600/1500 | 750 |
| 13R22.5 | 18 | 9.75 | 1124 | 320 | 154/151L | 3750/3450 | 850 |
| 12R22.5 | 17 | 9.00 | 1084 | 300 | 152/149M | 3550/3250 | 930 |
| 12.00R24 | 20 | 8.50 | 1226 | 313 | 160/157K | 4500/4125 | 900 |
| 12.00R20 | 20 | 8.50 | 1122 | 313 | 156/153K | 4000/3650 | 900 |
| 11R24.5 | 16 | 8.25 | 1100 | 279 | 149/146L | 3250/3000 | 830 |
| 11R22.5 | 16 | 8.25 | 1050 | 279 | 146/143M | 3000/2750 | 830 |
| 11.00R20 | 18 | 8.00 | 1082 | 286 | 152/149K | 3550/3250 | 930 |
| 10.00R20 | 18 | 7.50 | 1052 | 275 | 149/146K | 3250/3000 | 930 |
| 9.00R20 | 16 | 7.00 | 1018 | 258 | 144/142K | 2800/2650 | 900 |
| 9.5R17.5 | 18 | 6.75 | 842 | 240 | 143/141M | 2725/2575 | 930 |
| 8.25R20 | 16 | 6.50 | 974 | 236 | 139/137K | 2430/2300 | 930 |
| 8.25R16LT | 16 | 6.50H | 860 | 230 | 128/124K | 1800/1600 | 770 |
| 7.50R16LT | 14 | 6.00G | 802 | 210 | 122/118L | 1500/1320 | 770 |
| 7.00R16LT | 14 | 5.50F | 778 | 202 | 118/114K | 1500/1320 | 770 |
| 6.50R16LT | 12 | 4.50 | 755 | 182 | 110/105K | 1060/925 | 670 |
The above data is for reference only.
Tire parameters may be slightly different due to various tread designs from different manufacturers.
Tire Retread Process
If you are interested in Retreading your tires for recycling, feel free to contact us. Our Engineers will help to start the project with solutions from A to Z !
